40mm Finger protection panels
40mm Non-finger protection panels
50mm Non-finger protection panels for industrial use
1) Material: Galvanized steel with PU foaming inside2) Steel thickness: 0.35mm (Standard)3) Construction: sandwich/ steel-foaming-steel/ thriple layers4) Surface finishes: wood grain, orange peel, no grain
5) Design: Cassette, Stripe lines, Fold
6) Panel length: 12000mm at max7) Panel width: 430mm-550mm, adjusted8) Standard color: White RAL90169) Stocked solid color: Brown RAL8014, Anthracite grey RAL7016, Silver RAL9006, Light beige RAL1019, Ebony RAL9004, Red RAL3000, Blue RAL5015
10) Stocked Timber color: Mahogany, Gold oak, Black walnut, Dark oak
1) Standard Single Track (SST): 1 pair vertical track, 1 pair horizontal track, needs min headroom 350mm;
2) Standard Double Track (SDT): 1 pair vertical track, 1 pair horizontal track, 1 pair LHR horizontal track, needs min headroom 150mm;
3) L Profile support with Single Track (LST): 1 pair vertical track, 1 pair horizontal track with L profile support, needs min headroom 350mm;
4) L Profile support with Double Track (LDT): 1 pair vertical track, 1 pair horizontal track, a pair LHR horizontal track, with L profile support, needs min headroom 200mm
5) L Profile support with Double Track & ABS curve (SLDT) : 1 pair vertical track, 1 pair horizontal track, a pair LHR horizontal track, L profile with ABS curve, needs min headroom 200mm
6) Emergency lock for manual operation when power off
7) Torsion spring, or Tension spring
8) Hinges, Cable drum with cable, Central bracket with bearing, Mounting brackets and other accessories for a complete set
1) Rolling code2) Input power: AC220V, 50HZ/ AC110V, 60HZ
3) Motor power: DC 24V4) Radio frequency: 433.92MHz5) Output torque: 8N.M, 10N.M, 12N.M, 15N.M6) Max lifting height: 3.6m7) Working environment: -20°C to +70°C8) Protection class: IP209) Standard equipment: 2 transmitters, steel guide and other mounting brackets10) Options: wall switch, photocell, wireless pin code lock, back-up battery
Competitive Advantage of us:
1. Low MOQ: One set is available for checking our quality first conveniently.
2. Good Quality: Your client satisfied on our quality. You can get good reputation from your market and obtain more orders.
3. Good Service: Our professional service before and after sale.
4. The reasonable price
5. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
6. OEM is welcome
7. Rot-proof rubber seal for maximum light and air sealing between the sections.
8. Energy saving heat insulation due to high-strength PU rigid foam. The special foam meets the high quality requirements of industrial doors.
9. High-level resistance to bending and twisting. Secures garages against burglars and makes your door wind and weather proof.
10. Robust surface, easy to clean, the finished surface is extremely robust and easy to maintain.
Q1: What is your MOQ?
A: Our min order is one 20ft fll container. Sample order is available but we there will be sample charge. We also suggest wooden cases package for protection during shipment.
Q2: What is the Max available size of the panels?
A: The max length of panels can be 11.9M to suit the 40ft container. The max width of panels is 550mm.
Q3: Do you have CE certification?
A: Yes, we do have CE certification. We have CE for our complete automatic garage doors.
Q4: Can I get a sample of garage door for quality check?
A: Sample is available.
Q5: How can I get a price of needed garage door?
A: Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.
Q6: What kinds of payment you accept?
A: We usually accept T/T, L/C, Western Union, etc. If you prefer other payments terms, please feel free to discuss with us.
We achieved win-win in business, we are also friends.
--Mr Sam Leo-Andoh
MASTER can offer a wide variety of garage doors for homes and businesses. Their doors make our company perfect solution to our customers.
---Mr Adam Seipl
They are reliable business partner. Garage doors from MASTER add a functional and distinctive appearance to our business.
--- Mr. Arbi Sofian
I visited their factory and checked their garage doors. They are very professional. I placed my order to them immediately.
Choose us, not only your suppliers but also your good friends!
