Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: MASTER
  • Model Number: 77 Series rolling profile
  • Open Style: Rolling
  • Position: Commercial
  • Surface Finishing: Finished
  • Type: Entry Doors
  • Door Material: Aluminum Alloy
  • Material A: Extruded Alumium
  • Material B: Aluminum with PU foamed
  • Door type: Rolling
  • Door profile: Rolling profile
  • Covering width: 77mm
  • Color: White, any other RAL Code color
  • Max door width: 6000mm
  • Max door heigth: 5000mm
  • Application: Exterior entry door for commerical use

Packaging & Delivery

Packaging Details Rolling shutter door packed in wooden case/carton
Delivery Time Shipped in 25 days after payment

Master rolling shutter door/aluminum rolling shutter door/Automatic rolling door of Description:



Roller door profile

1. Rolling door profile: 77mm series

2. Covering surface: 77mm

3. Total width: 86mm

4. Surface finish: anti-scratch coated

5. Color:normal color is white, any other color customized as your order

6. Length: Customized as customers’ request

7. Max length for delivery: 7.5M

8. Application: for rolling doors, for residential and commercial use

9. Control:electric operation with manual control, or eletric operation only

10. Material A: Extruded aluminum alloy

11. Material B: Aluminum with PU foaming



Accessories

Aluminum rolling door / Roller door with roller up electric operation of Applications:





Item noPattenMaterialThicknessWeight/m2Max widthMax heightMax area
MR.RP77APAluminum alloy0.46mm5.0KG/M25000mm4000mm19m2
MR.RP77SGalvanized steel0.3mm9.0 KG/M24500mm3500mm14m2
0.35mm9.6 KG/M25000mm4200mm20m2
MR.RP77AH Extruded aluminum alloy1.0mm9.2 KG/M26500mm6500mm35m2
MR.RP77CExtruded aluminum alloy1.2mm6.85 KG/M25500mm4000mm20m2





Specifications

 Aluminum rolling door / Roller shutter door / Automatic Rolling door

1. Profiles: use of energy-saving roller profiles, made of high-quality pre-painted raw material, cold roll forming by filling high-grid polyurethane foam insulation. Special industrial surface treatment, resistance to climate, and anti-corrision;

2. Insulation: High-grid polyurethane foam with good insulation properties;

3. Good Sealing Performance: Aluminum end slats with sealing profiles, low noise, fast open, security performance;

4. High Level of Operating Performance: Operating system can be equipped with button control, remote control, all from move operation, infrared security system.



1. Dimension: can be customized

2. System option: tubular motor driving system, industrial side motor driving system

3. Slats option: 55mm, 77mm, 95mm.

4. Maxi width: 3500~8500mm.

5. Maxi height: 3500~6500mm.

6. Maxi coverage: 10.5~50 m2

7. Material: aluminum alloy/ Galvanized steel

8. Control: remote control

9. Motor: tubular motor or industrial rolling door motor

10. Normal color: white, light beige, Black, Brown



Different sizes of foam slats



Insulation Slats

Weight

KG/M2

Max available width

MM

Max available height

MM

Max available area

M2

Qty/m

Pcs

55mm

3.8

3500

3500

10.5

18.2

77mm

0.46

5000

4000

19.0

13

95mm

0.45

8500

6500

50

10.5
